| BRAND | Elettrotec |
| Product | 37100 IFE4R24 |
| Description | electric flow switch |
| Internal code | IMP114266 |
| Weight | 0.485 |
| Custom code | 90261081 / 90268020 |
| Technical specification | ECO 3 - 24 l/min Electric flow switch adjustable Contact type: Opener - opens the contact when the switch point falls below the set switching point. For media with low viscosity, such as water and water/glycol mixtures Material: nickel-plated brass Maximum working voltage: 220V - 50Hz Maximum power load in DC mode: 20W Maximum current load in AC mode: 20VA Breakdown voltage: 300V Protection class: IP65 Flow rate: 3 - 24 l/min Max. pressure: 50bar Maximum pressure loss with H2O: 0.5bar Working temperature: -10°C... +80°C Installation length: 115mm Connection thread: G1/2" Installation position: vertical - max. inclination 15° Flow direction: from bottom to top In accordance with CE 89/336 The flow switch must be installed at least 50 mm away from components that influence the magnetic field. |
