Prices Z3D-635-LG90 ZD0000001 Z-LASER Bulgaria

BRAND	Z-LASER
Product	Z3D-635-LG90 ZD0000001
Description	Z-LASER model Z3D-635-lg90 Output power: 3 mW / 635nm Dimensions: ø11x51mm Housing: chrome-plated brass black Protection: IP40 Focus: 1000mm Line length approx .: 1m at a distance of 1m and 45 ° inclination of the laser Line width approx .: 1mm in focus Supply: 3-6V DC (Imax = <300mA) Working temperature: -10 ° C to + 40 ° C Life: 25.000h at 23 ° C Electronics: APC with current limiter Connection: 2m cable with plug Laser Class: 1M (EN 60825-1: 2007) Standards: CE Warranty: 12 months with Z-LASER power supply
Internal code	IMP490036
Weight	1
Technical specification	(Projektion Standardlinie, 90° Öffnungswinkel Ausgangsleistung 3mW Wellenlänge 635nm Durchmesser 11mm Länge 51mm Fokus 1.000mm Versorgungsspannung 3-6VDC Betriebsart APC Anschluss 2m Kabel mit Stecker für WPSB Betriebstemperatur -10°C bis +40°C Gehäuse Messing, schwarz verchromt Schutzart IP40 Laserklasse (EN 60825-1:2007) 1M Garantie 12 Monate Optik lg90)

Z-LASER - Z3D-635-LG90 ZD0000001 referenced Z-LASER model Z3D-635-lg90 Output power: 3 mW / 635nm Dimensions: ø11x51mm Housing: chrome-plated brass black Protection: IP40 Focus: 1000mm Line length approx .: 1m at a distance of 1m and 45 ° inclination of the laser Line width approx .: 1mm in focus Supply: 3-6V DC (Imax = <300mA) Working temperature: -10 ° C to + 40 ° C Life: 25.000h at 23 ° C Electronics: APC with current limiter Connection: 2m cable with plug Laser Class: 1M (EN 60825-1: 2007) Standards: CE Warranty: 12 months with Z-LASER power supply product produced by high technology.
Z3D-635-LG90 ZD0000001 became irreplaceable of foundations. Z3D-635-LG90 ZD0000001 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.
